Camera IP Wifi EZVIZ C6T CS-CV248-A3-32WMFR

C6T - Mini 360 Plus

Camera

Name

CS-CV248

Model

1080p Pan and Tilt Wi-Fi Indoor Cloud Camera

Image Sensor

1/3' Progressive Scan CMOS

Min. Illumination

0.02Lux @ (F2.0, AGC ON) , 0 Lux with IR

Shutter Time

1/30s to 1/100,000s

Lens

4mm @ F2.2

Horizontal View Angle: 72°, Diagonal View Angle: 95°

Lens Mount

M12

Angle Adjustment

Panning angle: 0~340°, Tilting angle: -10~80°

Day & Night

IR Cut Filter

DNR

3D DNR

IR Range

Up to 33 feet (10m)

WDR

Digital WDR

Audio

Built-in Microphone and Speaker

Compression

Video Compression

H.264 Main Profile

Video Bit Rate

Hi-Def, Standard, adaptive bit rate.

Audio Bit Rate

Adaptive bit rate


Max. Resolution

1920*1080

Frame Rate

Up to 15fps@1920*1080, 30fps@1280*720,Adaptive

Network

Storage

Support microSD card (≤ 128 GB)

Smart Alarm

Smart motion detection, motion-tracking

One-key Configuration

SmartConfig (Wi-Fi one-key configuration)

Interface Protocol

EZVIZ Cloud Proprietary Protocol

Three color Indicators

Blue: normal mode Orange: privacy mode or motion tracking mode Red: network problem

General Function

Dual-stream, Mirror image

Wireless parameters

Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz to 2.4835 GHz

Channel Bandwidth

Support 20MHz

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate

802.11b: 11Mbps, 802.11g: 54Mbps, 802.11n: 150Mbps

Network Interface

1*RJ45 10M/100M Self-Adaptive Ethernet Port

General

Operating Conditions

-14°F to 131°F (−10°C~ 55°C), humidity less than 95% (non-condensing)

Power Consumption

5VDC ± 10%, 6W Maximum

Dimensions (inch)

3.94*3.94*3.54'(100mm*100mm*90mm)

Weight

0.48 lb (220g)
